AAEON AEC-VS01 User Manual
Page 28
E m b e d d e d C o n t r o l l e r
A E C - V S 0 1
Chapter 2 Hardware Installation
2 - 14
Step 3: Insert the RAM to the memory slot
Step 4: Press the RAM and make sure that it has been inserted properly.
P.S. If you are going to remove the RAM, you have to release the two
latches on two sides of the memory slot.
Latches
