E T X C a r r i e r B o a r d

E C B - 9 0 2 M

Chapter 1 Quick Installation Guide

1-16

2-3

No output filter cap

1.40 Audio MIC Input Cap Selection (JP37)

JP37 Function

1-2

Input filter cap(Default)

2-3

No input filter cap

Note:

JP33-JP37(For ETX-625,ETX-821,ETX-855,ETX-700,ETX-700B,

ETX-701, ETX-CX700M,please use Default.)

1.41 ISA Connector (CN3, CN4)

Standard ISA Slot

1.42 IR Connector (CN6)

Pin

Signal

1 +5V

2 N.C.

3 IRRX

4 GND

5 IRTX

1.43 Digital I/O Connector (CN7)

Pin Signal

1 OUT0

2 OUT1

3 OUT2

4 OUT3

5 OUT4

6 OUT5

7 OUT6

8 OUT7
