Signal – AAEON PER-U01H User Manual
Page 15
Au d i o D a u g h t e r B o a r d
P E R - U 0 1 H
Chapter 2 Quick Installation Guide
2-6
2.5 CD-in (J1)
Pin
Signal
1 CD-L
2 CD-GND
3 X
4 CD-R
2.6 Front Header (J2)
Pin Signal
Pin
Signal
1 MIC2-L
2 GND
3 MIC2-R
4 X
5 LINE2-R
6 MIC2-JD
7 GND
8 X
9 LINE2-L
10
LINE2-JD
2.7 HAD in (CN3)
Pin Signal
Pin
Signal
1 Azalia-RESET
2 Azalia-SYNC
3 Azalia-SDIN
4 Azalia-SDOUT
5 GND
6 Azalia-BCLK
7 GND
8 +5V
9 X
10
+3.3V
