AAEON AEV-6312 User Manual
Page 33
E m b e d d e d C o n t r o l l e r
A E V - 6 3 1 2
Chapter 2 Hardware Installation
2 - 18
2.10 Power Management
AEV-6312 has special vehicle Power Supply Unit (PSU) that can provide
power management functions below for vehicle applications.
Over voltage protection
Under voltage protection
Reverse
protection
Load dump protection
Programmable ACC power on/off delay time
PSU
Jumper 2
AEV-6312 PSU & jumper 2
VCC GND ACC
PSU power connector pinout
