background image

M i n i - P C I e

V i d e o C a p t u r e M o d u l e

P E R - V 3 6 C

PER-V36C Quick Installation Guide

1-9

1.5 List of Connectors

Label

Function

CN1

Channel 1 Audio/Video Input Cable Connector

CN2

Channel 2 Audio/Video Input Cable Connector

1.6 Channel 1 Audio/ Video Input Cable Connector (CN1)

Pin S i g n a l

P i n S i g n a l

1

S-Video – Chroma (C) Input

2

S-Video – Luma (Y) Input

3 GND

4 GND

5

CVBS – Composite Input

6

GND

7

Audio Input - R

8

Audio Input - L

9 GND

1.7 Channel 2 Audio/ Video Input Cable Connector (CN2)

Pin S i g n a l

P i n S i g n a l

1

S-Video – Chroma (C) Input

2

S-Video – Luma (Y) Input

3 GND

4 GND

5

CVBS – Composite Input

6

GND

7

Audio Input - R

8

Audio Input - L

9 GND
