A d v a n c e d S ys t e m
C o n t r o l l e r
A I S - E 1 - H 6 1 A
Chapter 2 Hardware Installation 2-10
2.14 1000Base-T Ethernet Connector with Dock USB 2.0
Connector (CON17/CON18)
Pin Signal Pin Signal
1 +5V 2 USB2_DN2
3 USB2_DP2 4 GND
5 +5V 6 USB2_DN1
7 USB2_DP1 8 GND
9 LAN_CTR 10 LAN_MDI_DP0
11 LAN_MDI_DN0 12 LAN_MDI_DP1
13 LAN_MDI_DN1 14 LAN_MDI_DP2
15 LAN_MDI_DN2 16 LAN_MDI_DP3
17 LAN_MDI_DN3 18 GND
19 LAN_LED_ACT 20 LAN_LED_ACT#
21 LAN_LED_LINK100# 22 LAN_LED_LINK1000#
23 GND 24 GND
25 GND 26 GND
27 GND 28 GND
29 GND 30 GND
2.15 Digital I/O Connector (DIO)
Pin Signal Pin Signal
1 DIO_I#1 (DIO_P#1) 2 DIO_I#2 (DIO_P#2)
3 DIO_I#3 (DIO_P#3) 4 DIO_I#4 (DIO_P#4)
5 DIO_O#1 (DIO_P#5) 6 DIO_O#2 (DIO_P#6)
7 DIO_O#3 (DIO_P#7) 8 DIO_O#4 (DIO_P#8)
9 +5V 10 GND
