T o u c h P a n e l P C A H P - 1 0 7 0
Chapter 2 Quick Installation Guide 2 - 2
2.1 Panelmount Installation
The display panel can be mounted into the wall. You will need the
screws along with the mounting brackets, which be packed in the
accessory box. Follow the steps below:
Before you start to follow the instructions, please place the
display panel into the wall. See the following illustration on the
left.
Step 1: Place the mounting brackets and plug the screw.
Step 2: Aim the mounting set at the hole on the monitor.
Step 3: Fix the monitor with the mounting set by screwing it.
Step 4: You’ve completed the preliminary when the mounting set
is tightened. Next, repeat the steps and tighten all
mounting set around the monitor until the monitor is
firmly mounting on the wall.
Sponge
