F u l l - s i z e S B C F S B - B 7 5 G
Chapter 2 Quick Installation Guide 2 - 6
DIO1 Digital I/O Pin Header
FDD1 Floppy Pin Header
LPT1 Parallel Port Pin Header
USB1 USB 3.0 Pin Header
USB5 USB 3.0 Pin Header
USB2 USB Pin Header
USB3 USB Pin Header
USB4 USB Connector
USB6 USB Connector
BT1 Battery
SATA1~SATA3 SATA Connector
LAN1 10/100/1000 Base Ethernet Connector
LAN2 10/100/1000 Base Ethernet Connector
DIMM1 DDR3 DIMM Slot
DIMM2 DDR3 DIMM Slot
CPU_FAN 4 Pin Fan Connector
SYS_FAN 4 Pin Fan Connector
VGA1 VGA Connector
