RTC-900B
System
Processor Intel® Atom™ E3825 Series Processor
System Memory DDR3L SDRAM, 2 GB (Up to 4GB)
LCD Display
10.1” WXGA (1280 x 800) 16:10 TFT LCD with Projected Capacitive Multi-Touch
screen
Communication WiFi 802.11 a/b/g/n, Bluetooth® 4.0, 3G modem module (optional)
I/O Port
DC-in Jack x 1, Mini USB Port x 1, Mini HDMI x1, Micro SD Card Slot x 1, 3.5
mm stereo headphone jack x 1,Built-in Speaker & Microphone, SIM Card Slot
x 1
Storage 32/64GB mSATA
Navigation GPS, AGPS
Camera Front camera: 2Mega, Real camera: 5Mega
Other Built-in Light Sensor, Built-in G-Sensor
OS
Windows® Embedded 8 Standard (Default)
Windows® Embedded 8 Industry Pro (Optional)
MTBF (Hours) —
Mechanical
Color Black
Dimension 10.65” x 7.42” x 0.96” (270.4mm x 188.4mm x24.29 mm)
Gross Weight 2.4 lb (1.1 Kg)
Environmental
Operating Temperature -4°F ~ 131°F (-20°C ~ 55°C)
Storage Temperature -67°F ~ 131°F (-55°C ~ 55°C)
Water & Dust Proof IP65 compliance
Vibration
Meets MIL-STD 810G-514.6, Procedure I Cat. 24, Fig. 514.6E-1 & 514.6E-2
(Unit is non-operating), ASTM 4169-99 Truck Assurance Level II, Schedule E
(Unit is operating)
Drop
26 drops of 48 inches height to 2 inches plywood over concrete with unit off,
MIL-STD 810G-516.6, Procedure IV
ESD Air +/- 8KV, Contact +/- 4KV
EMC/ Safety CE / FCC Class B / UL
■ ■ Intel® Atom™ E3825 Series Processor
■ ■ DDR3L SDRAM 2GB
■ ■ 10.1” WXGA (1280 x 800) TFT LCD Display
■ ■ Projected Capacitive Multi-Touch Screen
■ ■ Li-Polymer High-Capacity Battery, 7 Hours Battery Life
■ ■ Rugged, Water and Dust Proof, IP65 Compliance
■ ■ Micro SD Card Slot, 5M Pixel Camera
■ ■ WLAN 802.11 a/b/g/n, Bluetooth® 4.0
■ ■ GPS Navigation, G-Sensor, Light Sensor
■ ■ Windows® Embedded 8 Standard (Default);
Windows® Embedded 8 Industry Pro (Optional)
10.1” Rugged Tablet Computer with Intel® Atom™ E3800 Series Processor
Light Sensor
Front Camera
Rear Camera (5MP)
Speaker
SIM
Earphone
Power Button
micro SD
DC-in
HDMI
Mini USB
2014/05/14
Features
Specifications
Ru
gg
ed
T
ab
le
t C
omp
uter
s
