Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector Connector
Label
Function
Vendor Model no
Available
Cable
Cable P/N
CN1 CD-IN HO
BASE
2.54mm Pitch 4
pins (HO-BASE
2541-1H-4 or
compatible) CDROM
Cable 1703040400
CN2 Digital I/O Catch 2.00mm Pitch 10
pins ( Catch
H754-2x5 or
compatible) NA NA
CN3 TV-Out Catch 2.00mm Pitch 8
pins ( Catch
H754-2x4 or
compatible)
TV-Out
Cable 1700080180
CN4 Internal
Keyboard
HO
BASE
2.54mm Pitch 5
pins (HO-BASE
2503-H-5 or
compatible) NA NA
CN5 Fan Catch 2.54mm Pitch 3
pins (Catch
1190-700-03S or
compatible)
NA NA
CN6 Audio 5.1
Channel/
SPDIF
Catch
2.00mm Pitch 14
pins ( Catch
H709-2 or
compatible) Audio
Cable 1700140164
CN7 Internal
Mouse
HO
BASE
2.0mm Pitch 4
pins (HO-BASE
2002-H-4 or
compatible) NA NA
CN8 LCD
Inverter
HO
BASE
2.0mm Pitch 5
pins (HO-BASE
2002-H-5 or
compatible) NA NA
