M i n i - I T X E M B - A 7 0 M
Chapter 2 Quick Installation Guide 2 - 12
3 +12V 4 +12V
2.16 SATA Connector (SATA 1~5)
Pin Signal Pin Signal
1 GND 2 TXP
3 TXN 4 GND
5 RXN 6 RXP
7 GND
2.17 USB3.0 Connector (USB3_34)
Pin Signal Pin Signal
1 +5V_USB3_2_P1 11 +5V_USB3_2_P2
2 U3_2_U3RXDN1 12 U3_2_U3RXDN2
3 U3_2_U3RXDP1 13 U3_2_U3RXDP2
4 GND 14 GND
5 U3_2_U3TXDN1 15 U3_2_U3TXDN2
6 U3_2_U3TXDP1 16 U3_2_U3TXDP2
7 GND 17 GND
8 U3_2_U2DN1 18 U3_2_U2DN2
9 U3_2_U2DP1 19 U3_2_U2DP2
10 NA 20 NA
