AAEON GENE-QM77 Rev.B User Manual
Page 109
S u b C o m p a c t B o a r d
G E N E - Q M 7 7 R e v . B
Select Primary IGFX boot display device
Note1: CRT, DVI and CRT+LVDS1 are not available in some Suks.
Note2: LVDS1 is the default main display device when this item has
been set to “Auto Detect” and enabled LVDS1.
In this case, DVI/HDMI will not display in DOS system unless user
sets this item to DVI or HDMI manually.
Enabled
Onboard LVDS1
Disabled
Enable or Disable Internal LVDS
Enabled
Onboard LVDS2
Disabled
Enable or Disable Onboard CH7511
640x480 18-Bit
800x600 18-Bit
1024x768 18-Bit
800x480 18-Bit
1024x600 18-Bit
1280x768 18-Bit
640x480 24-Bit
800x600 24-Bit
1024x768 24-Bit
1280x1024 48-Bit
1280x768 24-Bit
LVDS1/LVDS2 Panel
Type
1366x768 24-Bit
Chapter 3 AMI BIOS Setup 3-48
