S u b C o m p a c t B o a r d

G E N E - Q M 6 7

Chapter 2 Quick Installation Guide

2 - 22

2.39

tek LAN (R

rt (CN23)

Real

J-45) Po

Pin Signal

1 BI_DA+

2 BI_DA-

3 BI_DB+

4 BI_DC+

5 BI_DC-

6 BI_DB-

7 BI_DD+

8 BI_DD-

2.40

LAN (RJ-

(CN24)

Intel

45) Port

Pin Signal

1 BI_DA+

2 BI_DA-

3 BI_DB+

4 BI_DC+

5 BI_DC-

6 BI_DB-

7 BI_DD+

8 BI_DD-

2.41 USB Port 1 and 2 (CN25)

Pin Signal

1 VCC

(+5V)

2 D-

3 D+

4 GND
