P C 1 0 4 C P U M o d u l e P F M - 5 4 0 I
Chapter 2 Quick Installation Guide 2- 19
18-bit TTL
Pin Signal Pin Signal
1 +5V 2 +5V
3 GND 4 GND
5 +3.3V 6 +3.3V
7 ENBKL 8 GND
9 N.C 10 N.C
11 BLUE0 12 BLUE1
13 BLUE2 14 BLUE3
15 BLUE4 16 BLUE5
17 N.C 18 N.C
19 GREEN0 20 GREEN1
21 GREEN2 22 GREEN3
23 GREEN4 24 GREEN5
25 N.C 26 N.C
27 RED0 28 RED1
29 RED2 30 RED3
31 RED4 32 RED5
33 GND 34 GND
35 CLOCK 36 VSYNC
37 DE 38 HSYNC
39 N.C 40 ENAVEE
