P C / 1 0 4 M o d u l e P F M - C V S R e v . B
1.3 Specifications
System
z
Form Factor PC/104
z
Processor Intel
®
Atom™ N2600 1.6 GHz
processor
z
System Memory 204-pin DDR3 1067 MHz
SODIMM x 1, Max. 2 GB
z
Chipset Intel
®
Atom™ N2600+ NM10
z
I/O Chipset Fintech F81866D
z
Ethernet Intel 82583V for
10/100/1000Base-TX, RJ-45x 1
z
BIOS AMI BIOS – 32MB ROM
z
Wake on LAN Yes
z
Watchdog Timer Generates a time-out system
reset
z
H/W Status Monitoring Supports power supply voltage
and temperature monitoring
z
Expansion Interface PC/104+, mSATA/ Mini Card(
Half/Full size supported)
z
Power Requirement +12V, AT (Default) /ATX
z Battery
Lithium battery
z
Board Size 3.78” x 4.05” (96mm x 103mm)
z
Gross Weight 0.35 lb (0.16 Kg)
Chapter 1 General Information 1- 4
