P C / 1 0 4 C P U M o d u l e P F M - 5 4 0 I R e v . B
Chapter 1 General Information 1- 4
1.3 Specifications
System
Processor AMD Geode LX 800 (500MHz)
Processor
System Memory 200-pin Onboard DDR SDRAM
SODIMM x 1, Max. 1GB for DDR333
and 512MB for DDR 400 (Please refer
to the Quick Installation Guide 2.27
DDR1 SODIMM Slot for details)
Chipset AMD LX 800 + CS5536
I/O Chipset
SCH3114-NU (SMSC3114i-NU for
WiTAS series products)
Ethernet
Intel 82551ER, 10/100Mbps,
RJ-45 x 1 (Intel 82551IT for WiTAS
series products)
BIOS
Award 1MB Flash ROM
PCI to ISA solution
ITE 8888
Watchdog Timer 255 levels
RTC
CS5536
Hardware Monitor
SMSC SCH3114
Solid Storage Disk
CompactFlash™ Type I x 1
Expansion Interface
PC/104 socket x 1
Power Requirement +5V/AT
Board Size
3.55”(L) x 3.775”(W) (90mm x 96mm)
