Appendix B Mating Connector
C - 2
B.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector
Connector
Label
Function
Vendor
Model no
Available Cable AAEON Cable
P/N
CN1
2P Power
Connector
N/A N/A
Power
cable(option)
1702002010
CN2
Front Panel
Connector
Molex
Molex
51021-0800
LAN LED Cable 1701080150
CN3
Front Panel
Connector
Molex
Molex
51021-1000
Front Panel
Cable
1701010150
CN4
JTAG
Connector
CATCH
2.00mm
Pitch 8
pins
( CATCH
H754-2x4 or
compatible)
N/A N/A
CN5
COM port
Connector
CATCH
2.00mm
Pitch 40
pins
( CATCH
H754-2x20
or
compatible)
COM port Cable 1701400205
CN6
TTL LCD
Connector
Hirose
1.25mm
Pitch 40
pins
( CATCH
H716 or
compatible)
LCD Cable
N/A
CN8
PS2
Keyboard/
Mouse
Connector
CATCH
(CATCH
MD-6PS or
compatible)
Keyboard &
Mouse Cable
1700060152
CN9
4P power
Connector
Ever 2542H-04
N/A
N/A
VGA1
VGA
Display
Connector
CATCH
2.00mm
Pitch 16
pins
( CATCH
H754-2x8 or
CRT Cable
1701160201
