P C / 1 0 4 P e r i p h e r a l M o d u l e P F M - C 4 2 C
PFM-C42C Quick Installation Guide 1-20
1.22 RS-232 Serial Port Connector (COM8) (For 8-port only)
Pin S i g n a l P i n S i g n a l
1 DCD#8 2 RXD8
3 TXD8 4 DTR#8
5 GND 6 DSR#8
7 RTS#8 8 CTS#8
9 RI#8 10 N.C
1.23 Driver Installation
The PFM-C42C supports Linux and Windows XP platforms. It comes
with a CD-ROM that contains all drivers and utilities that meet your
needs. When your platform is Windows XP please following the
sequence below to install the drivers, when your system is Linux,
you don’t need to install the driver just process the Mini PCI RS-232
module set up in Linux
Installing Mini PCI RS-232 drivers in Windows XP
Once the card is installed and the computer is restarted, Windows
will detect the board and attempt to load the drivers for it.
1. Windows will detect a “PCI Serial Port”. Select “Install
from a list or specific location (Advanced)” as the shown of
figure 1. Click “Next.”
