GEARENCH U120-12 PETOL HYDRA-TORK - Manual (Page 24)

22
Hydraulic Schematic Parts List
Item Qty. Part Number Description Make / Model Notes
1 1 UHCH-P09 Pump Oilgear
PVWH-34-LDFY-HNNNN-
TKCP-XXXC
2 1 UHCH-M15 Motor Baldor
CM2333 Or equal
3 1 UHCH-M16 Motor coupling Magnalloy
M30012012 Or equal
4 1 UHCH-M17 Pump coupling Magnalloy
M30010810 Or equal
5 1 UHCH-M18 Coupling insert Magnalloy
M370U Or equal
6 1 UHCH-P10 Adaptor Magnalloy
M182682C Or equal
7 1 UHCH-V37 Manifold Daman
AD07P24S/S Or equal
8 1 UHCH-V08 Relief valve Sun
RPGC-LCN-3200psi Or equal
9 1 UHCH-V36 Directional valve Rexroth
4WEH16R7X/6EG24N9ETK4
10 1 UHCH-V38 Manifold reducer Daman
AD03D07VAAB Or equal
11 1 UHCH-V11 Directional valve Wandfluh
WDMFA06-AC2-R24
12 1 UHCH-V02 Pressure control Sun
RSDC-LAN-EHI
13 1 UHCH-V03 Power limit valve Sun
NFCC-LDN-GAI
14 1 UHCH-G01 Pressure gauge Wika
213.40 4” FF-LBM 3000psi Or equal
15 2 UHCH-G05 Gauge snubber Cajon
SS-4-SA-EW Or equal
16 1 UHCH-B04 Filter element Hycon
0180-MA-010-P Or equal
25 1 UHCH-B02 Filter switch Nason
SM-2A-15R/HR Or equal
26 1 UHCE-P1 Pressure transducer Omega
PX602-3KGV
Or equal
