Tong Assembly Parts List
Item Qty. Part Number Description
1 1 UVTDH118 Handle
2 1 HP276
Handle pin
3 1 TVJ118 Jaw
4A 2 HI10D Diamond point insert
4B 2 HI10B Blank insert
5 4 HP904 Insert key
6 4 HS21 Insert key spring
7 1 TVP118V Pawl
8 1 TVL118V Pawl
latch
9 1 HP300 Pawl latch pin
10 1 HP327 Pawl latch rivet
11 1 HS01 Pawl latch spring
12 1 HP294 Jaw pin w/ kliprings
13 2 HXRR225 Jaw pin klipring only
31
