Torque capacity
The Surgrip Casing Tong utilizes a different belt for each nominal diameter. The maximum
working loads are shown in the table below.
Diameter
Belt
Part
Number
Torque
Arm
Length
(inches)
Maximum
Torque
(foot-pounds)
Maximum
Line Pull
(pounds)
9 5/8 SCTB1020-0958 46.31 49,400 12,800
9 7/8 SCTB1020-0978 46.44 49,500 12,800
10 SCTB1020-1000 46.50 49,600 12,800
10 3/4 SCTB1020-1034 46.88 50,000 12,800
11 3/4 SCTB1020-1134 47.38 50,500 12,800
11 7/8 SCTB1020-1178 47.44 50,600 12,800
12 3/4 SCTB1020-1234 47.88 51,100 12,800
13 3/8 SCTB1020-1338 48.19 51,400 12,800
13 5/8 SCTB1020-1358 48.31 51,500 12,800
14 SCTB1020-1400 48.50 51,700 12,800
16 SCTB1020-1600 49.50 52,800 12,800
16 3/4 SCTB1020-1634 49.88 53,200 12,800
17 SCTB1020-1700 50.00 53,300 12,800
18 SCTB1020-1800 50.50 53,900 12,800
18 3/8 SCTB1020-1838 50.69 54,100 12,800
18 5/8 SCTB1020-1858 50.81 54,200 12,800
20 SCTB1020-2000 51.50 54,900 12,800
WARNING: Under no circumstances should the maximum working load be
exceeded. Always use a load cell or other calibrated indicating device to monitor
the line pull on the tong to avoid an overload.
Use on couplings
The jaw has two belt anchoring holes. One hole is marked “PIPE”, when this hole is fixed to
the handle, the tong will latch on the pipe for the appropriate belt. The third hole is marked
“COUPLING”, this hole will allow the tong to be latched onto a coupling with a diameter of
one inch over the pipe diameter.
