Torque and Diameter Capacity
The following table lists the maximum working torques and the corresponding handle loads
for the diameter range of the tong.
Diameter
Torque
Arm
Length
(inches)
Maximum
Torque
(foot-pounds)
Maximum
Line Pull
(pounds)
6 34.22 56,100 19,700
6-1/2 34.36 56,200 19,600
7 34.51 56,300 19,600
7-1/2 34.65 56,500 19,600
8 34.80 56,600 19,500
8-1/2 34.94 56,700 19,500
9 35.09 56,800 19,400
9-1/2 35.23 56,900 19,400
10 35.38 57,100 19,400
10-1/2 35.52 57,200 19,300
11 35.66 57,400 19,300
11-1/2 35.81 57,500 19,300
12 35.95 57,600 19,200
12-1/2 36.10 57,800 19,200
13 36.24 57,900 19,200
13-1/2 36.39 58,100 19,200
14 36.53 58,300 19,100
14-1/2 36.67 58,400 19,100
15 36.82 58,600 19,100
15-1/2 36.96 58,700 19,100
16 37.11 58,900 19,000
16-1/2 37.25 59,100 19,000
17 37.40 59,200 19,000
WARNING: Under no circumstances should the maximum working load be
exceeded. Overloading may result in injury or death. Always use a load cell or
other calibrated indicating device to monitor the line pull on the tong to avoid an
overload.
