Set up and operation
4
Set up and operation
4.1 Setup
Fig. 2 V-DTN compressor
A
Suction
B Pressure
connection
D
Pressure regulating valve
E
Cooling air inlet
F
Cooling air outlet
G Outlet
grid
G
1
Inlet grating
N Data
plate
O
Rotation direction plate
E
G
1
D
B
G
F
N
E
O
F
A
