D SERIES OM−01476
MAINTENANCE & REPAIR PAGE E − 10
PARTS LIST
Gear Reducer
ITEM
NO.
PART NAME
PART
NUMBER
QTY
1 GEAR HOUSING AND GEAR HOUSING 93A119346−000 1
COVER SET
2 OUTPUT SHAFT ASSY G-R PROPRIETARY ITEM 1
3 INPUT PINION 93A118178−001 1
4 OUTPUT PINION ASSY 93A119546−000 1
5 INTERMEDIATE PINION ASSY 93A119548−000 1
6 INPUT PINION BEARING 93A113859−006 1
7 INTERMEDIATE PINION BEARING 93A113859−005 1
8 PUTPUT PINION BEARING 93A113859−004 2
9 COVER END OUTPUT SHAFT BEARING 04A12292−0300 1
10 HOUSING END OUTPUT SHAFT BEARING 04A12292−0100 1
11 LOAD RING 24A12293−0200 1
12 INPUT SHAFT OIL SEAL 40A02187−3900 1
13 OUTPUT SHAFT OIL SEAL 40A02187−3800 1
14 DOWEL PIN 24A12295−0200 2
15 5/16−18 x 1/2 HEX HD CAPSCREW STANDARD HARDWARE 4
16 5/16 LOCK WASHER STANDARD HARDWARE 4
17 PIPE PLUG 93A113412−003 3
18 VENT PLUG 93A113535−001 1
19 SNAP RING 24A09285−1800 2
20 SNAP RING 24A09284−0300 1
21 GASKET 93A119348−004 1
22 OUTPUT KEY 23A02741−3700 1
23 INPUT KEY 23A02741−3600 1
NOTE
The Gorman-Rupp Gear Reducer (P/N
24572−003) used in this pump is a proprietary item
manufactured by Dayton Electric Manufacturing
Company as a special model.
If replacement is necessary, the complete gear re-
ducer must be ordered exclusively from The Gor-
man-Rupp Company. Gorman-Rupp does not
stock or furnish any component parts for the gear
reducer.
However, all component parts, except the output
shaft, are identical to those used in the non-propri-
etary Model 2Z934 Gear Reducer, and may be ob-
tained from W.W. Grainger Inc., 5959 W. Howard St.,
Chicago, Illinois 60077, (312)647−8900,
www.grainger.com, or from any full stock W.W.
Granger distributor.
The output shaft is not available as a spare part ei-
ther from W.W. Grainger, Inc. or from Gorman-
Rupp. If the output shaft requires replacement, a
complete gear reducer must be ordered from The
Gorman-Rupp Company.
