OM−06223 60 SERIES
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 62 1/2A1−GX390 S/2
(Canadian S/N 106873 and up)
If your pump serial number is followed by an N", your pump is NOT a standard production model. Contact
the Gorman-Rupp Company to verify part numbers.
1 PUMP END ASSY 62 1/2A1−(GX390) 1
2 HONDA GX390 ENG 29122-036 −−− 1
3 HANDPRIMER S1252 −−− 1
4 HAND CARRY DECAL 2613FT −−− 2
5 PRESSURE GAUGE S180 −−− 2
6 RUBBER FOOT MTG KIT 48152-603 −−− 1
7 DISCHARGE STICKER 6588BJ −−− 1
8 SWIVEL FITTING 26571-002 −−− 1
9 .38 I.D. X 12" HOSE 18513-302 −−− 1
10 HOSE ADAPTOR 26523−334 2
11 PIPE BUSHING AP0806 15079 1
12 STREET ELBOW RS08 11999 1
13 HANDPRIMER BRKT 50784 −−− 1
. 14 WARNING DECAL 2613FE −−− 1
15 HEX HD CAPSCREW B0606 15991 4
16 FLAT WASHER K06 15991 4
17 FLANGED HEX NUT 21765-314 −−− 4
18 STUD C0606−1/2 15991 4
19 HEX NUT D06 15991 4
20 LOCKWASHER J06 15991 4
21 SUCTION STICKER 6588AG −−− 1
22 ROLLOVER BASE 41583-317A 24150 1
23 HEX HEAD CAPSCREW B0604 15991 4
24 LOCKWASHER J06 15991 4
25 HEX HEAD CAPSCREW B0604 15991 2
26 HEX NUT D06 15991 2
27 LOCKWASHER J06 15991 2
28 COUPLING 2469 14000 1
29 COUPLING 2469 14000 1
NOT SHOWN:
NAMEPLATE 38812−045 −−− 1
ENG. START UP TAG 38816-269 −−− 1
INSTRUCTION TAG 38817-085 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
