OM-02398 80 SERIES
MAINTENANCE & REPAIR PAGE E - 3
PARTS LIST
Pump Model 810A2‐B
(From S/N 819132 Up)
If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact
the Gorman‐Rupp Company to verify part numbers.
1 PUMP CASING 38224-704 10010 1
2 IMPELLER 38615-073 11010 1
3 GREASE SEAL ASSY GS1500 --- 1
4 IMPELLER ADJ SHIM SET 5091 17090 REF
5 DISCHARGE STICKER 6588BJ --- 1
6 DISCHARGE FLANGE 2751 10010 1
7 FILL PLUG ASSY 48271-069 --- 1
8 HEX HD CAPSCREW B1414 15991 12
9 HEX NUT D14 15991 12
10 DISCH FLANGE GASKET 2751G 18000 1
11 NAME PLATE 38818-024 13990 1
12 DRIVE SCREW BM#04-03 17000 4
13 CASING GASKET SET 48211-051 --- 1
14 STUD C0810 15991 8
15 HEX NUT D08 15991 8
16 IMPELLER WASHER 31167-018 15010 1
17 IMPELLER SCREW BD0804 15991 1
18 GREASE CUP S1509 --- 1
19 PIPE ELBOW AG04 11999 1
20 PIPE NIPPLE T0412 15079 1
21 PIPE ELBOW AG04 11999 1
22 PIPE NIPPLE T04 15079 1
23 OIL SEAL 25227-534 --- 1
24 INBOARD BALL BEARING S1030 --- 1
25 AIR VENT S1703 --- 1
26 ROTATION DECAL 2613M --- 1
27 PEDESTAL 3020B 10010 1
28 O‐RING 25152-245 --- 1
29 RETAINING RING S1165 --- 1
30 RD HD MACH SCREW X#10‐01‐1/2S 15991 2
31 LOCK WASHER J#10 15991 2
32 SHAFT KEY N0615 15990 1
33 IMPELLER SHAFT 38515-572 16040 1
34 OIL SEAL 25227-534 --- 1
35 BEARING RETAINER 38322-522 26000 1
36 BEARING ADJ SHIM SET 8546 15990 1
37 OUTBOARD BALL BRG S1077 --- 1
38 SIGHT GAUGE S1471 --- 1
39 PEDESTAL DRAIN PLUG P12 15079 1
40 PIPE PLUG P06 15079 1
41 O‐RING 25152-248 --- 1
42 BEARING CAP 38322-418 10010 1
43 STUD C0607 15991 6
44 HEX NUT D06 15991 6
45 LOCK WASHER J06 15991 6
46 SLINGER RING 3209 19120 1
47 CASING DRAIN PLUG PC24 10009 1
48 SEAL PLATE ASSY 42111-068 --- 1
49 PIPE PLUG P24 10009 1
50 O‐RING S1865 --- 1
51 WEAR PLATE 38691-860 10010 1
52 STUD C0808 15991 3
53 LOCK WASHER J08 15991 3
54 HEX NUT D08 15991 3
55 CASING DRAIN PLUG P20 10009 1
56 CHECK VALVE SEAT 3286 10010 1
57 SUCT FLANGE GASKET 2751G 18000 1
58 STUD C1215 15991 12
59 HEX NUT D12 15991 12
60 SUCTION FLANGE 2751 10010 1
61 CHECK VALVE ASSY 3289 --- 1
62 -VALVE WEIGHT 3287 10010 1
63 -HEX HD CAPSCREW B0605 17000 2
64 -LOCK WASHER J06 17000 2
65 -VALVE WEIGHT 3288 11000 1
66 -CHECK VALVE GASKET 3290 19080 1
67 PIPE PLUG P04 15079 1
68 SEAL LINER 7408 14010 REF
NOT SHOWN:
STRAINER 3756 --- 1
G‐R DECAL GR-06 --- 1
LUBE DECAL 38816-079 --- 1
SUCTION STICKER 6588AG --- 1
PRIMING STICKER 6588AH --- 1
GREASE CUP INSTR 6588AD --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
