OM−00892 80 SERIES
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 83B52−B
(From S/N 1329030 up)
If your pump serial number is followed by an N", your pump is NOT a standard production model. Contact
the Gorman-Rupp Company to verify part numbers.
1 PUMP CASING 38222−435 10000 1
2 IMPELLER 7422B 10010 1
3 SEAL ASSY 25285−855 −−−−− 1
4 DISCH FLANGE GSKT 543G 18000 1
5 STUD C0607 15991 4
6 HEX NUT D06 15991 4
7 DISCH STICKER 6588BJ −−−−− 1
8 FILL PLUG ASSY 48271−066 −−−−− 1
9 PRIMING STICKER 6588AH −−−−− 1
10 DISCH FLANGE 543 10010 1
11 IMPELLER ADJ SHIM SET 2X 17090 1
12 SPRING SEAT 31512−021 1706H 1
13 SHAFT SLEEVE 2146L 16000 1
14 SLINGER RING 3272 19120 1
15 INBOARD OIL SEAL 25227−311 −−−−− 1
16 INBOARD BALL BRG 23275−008 −−−−− 1
17 AIR VENT S1703 −−−−− 1
18 PEDESTAL 3114B 10010 1
19 ROTATION DECAL 2613M −−−−− 1
20 OUTBOARD BALL BRG 23275−008 −−−−− 1
21 BRG RETAINER O-RING 25152−235 −−−−− 1
22 RETAINING RING S247 −−−−− 1
23 BRG RET OIL SEAL 25227−303 −−−−− 1
24 ALLEN HEAD SETSCREW GA#10−01S 15990 2
25 SHAFT KEY N0407 15990 1
26 IMPELLER SHAFT 38514−549 15010 1
27 BEARING SHIM SET 48261−009 −−−−− 1
28 BEARING RETAINER 38322−521 26000 1
29 SIGHT GAUGE 26714−011 −−−−− 1
30 PIPE PLUG P06 15079 1
31 PEDESTAL DRAIN PLUG P06 15079 1
32 STUD C0607 15991 8
33 HEX NUT D06 15991 8
34 SEAL PLATE 3613A 10010 1
35 CASING GASKET SET 3GC 20010 1
36 WEAR PLATE ASSY 2899A 15990 1
37 WASHER 3118 15990 1
38 HEX HD CAPSCREW B0604 15991 1
39 T-TYPE LOCKWASHER AK06 15991 1
40 NAME PLATE 38818−022 13990 1
41 DRIVE SCREW BM#04−03 17000 4
42 CASING DRAIN PLUG P12 15079 1
43 FIBER WASHER KF06 18040 1
44 HEX HD CAPSCREW B0618 15991 1
45 FLAP VALVE ASSY 544A −−−−− 1
46 −FLAP VALVE GASKET 544G 19070 1
47 −LG VALVE WEIGHT 1364 10010 1
48 −SM VALVE WEIGHT 18 10010 1
49 −RD HD MACH SCREW X0403 17090 1
50 −LOCKWASHER J04 17090 1
51 ACCESSORY PLUG P04 15079 1
52 SUCTION FLANGE 2946 10010 1
53 STUD C0606 15991 4
54 HEX NUT D06 15991 4
55 SUCTION STICKER 6588AG −−−−− 1
56 ACCESSORY PLUG P04 15079 1
57 HEX NUT D06 15991 1
58 LOCKWASHER J06 15991 1
59 FILL PLUG ASSY 48271−066 −−− 1
NOT SHOWN:
LUBRICATION DECAL 38816−079 −−−−− 1
OPTIONAL:
METRIC FLANGE KIT 48213−074 −−−−− 1
−SUCTION FLANGE 38642−212 10000 1
−DISCHAGE FLANGE 38647−401 10000 1
−PIPE PLUG P04 15079 1
−FILL [PLUG 48271−066 −−− 1
FLANGE KIT 48213−107 −−−−− 1
−SUCTION FLANGE 38642−010 10000 1
−DISCHAGE FLANGE 38647−402 10000 1
−PIPE PLUG P04 15079 1
−FILL [PLUG 48271−066 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
