10 SERIES OM-00573
MAINTENANCE & REPAIR PAGE E - 3
PARTS LIST
Pump Model 11 1/2A20-B
(From S/N 519865N Up)
If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact
the Gorman‐Rupp Company to verify part numbers.
. 1 PUMP CASING SEE NOTE BELOW
2 IMPELLER 12368 10010 1
3 SEAL ASSY 46512-035 --- 1
. 4 PIPE PLUG P04 15079 1
. 5 FILL PLUG ASSY 48271-066 --- 1
6 NAME PLATE 38818-021 13990 1
7 DRIVE SCREW BM#04-03 17000 4
. 8 WARNING PLATE 2613EV 13990 1
. 9 DRIVE SCREW BM#04-03 17000 4
10 BOTTLE OILER S1933 --- 1
11 PIPE COUPLING AE04 15079 1
12 PIPE NIPPLE T0410 15079 1
13 RED PIPE BUSHING AP0402 15079 1
14 OIL SEAL S1659 --- 1
15 GREASE FITTING S1404 --- 1
16 OIL SEAL S1659 --- 1
17 INBOARD BALL BEARING S1403 --- 1
18 VENTED PLUG 4823 15079 1
19 PEDESTAL 8852B 10010 1
20 ROTATION DECAL 2613M --- 1
21 BEARING ADJ SHIM SET 8540 15990 1
22 GREASE FITTING S1404 --- 1
23 HEX HD CAPSCREW B0404 15991 4
24 LOCK WASHER J04 15991 4
25 BEARING CAP 8853A 10010 1
26 SHAFT KEY N0307 15990 1
27 IMPELLER SHAFT 38514-004 15010 1
28 OIL SEAL S1659 --- 1
29 PEDESTAL FOOT 8857 24000 1
30 OUTBOARD BALL BRG S1403 --- 1
31 SLINGER RING 3228A 19120 1
32 PIPE PLUG P04 15079 1
33 SHAFT SLEEVE 31411-097 17130 1
.34 STUD C0607 15991 4
35 HEX NUT D06 15991 4
36 SEAL PLATE 38272-114 10010 1
37 CASING GASKET SET 504G 18000 1
38 WEAR PLATE 2643 15990 1
39 HEX NUT D04 15991 2
40 LOCK WASHER J04 15991 2
.41 PIPE PLUG P06 15079 1
42 COVER PLATE GASKET 12369G 20000 1
43 CLAMP BAR SCREW 8618 24000 1
44 BACK COVER PLATE 12369 10010 1
.45 HEX HD CAPSCREW B0808 15991 2
46 CLAMP BAR 12370 11010 1
47 SUCTION FLANGE 8599 10010 1
48 CHECK VALVE ASSY 1352 --- 1
49 -RD HD MACH SCREW X0403 17090 1
50 -LOCK WASHER J04 17090 1
51 -SMALL VLV WEIGHT 1354 15160 1
52 -CHECK VLV GASKET 1352G 19070 1
53 -LARGE VLV WEIGHT 1353 10010 1
.54 STUD C0606 15991 4
55 HEX NUT D06 15991 4
56 SPRING CTR WASHER 31512-010 17030 1
57 IMP ADJ SHIM SET 513A 17090 1
NOT SHOWN:
SUCTION STICKER 6588AG --- 1
PRIMING STICKER 6588AH --- 1
DISCHARGE STICKER 6588BJ --- 1
INSTRUCTION TAG 38817-011 --- 1
INSTRUCTION TAG 38817-010 1
LUBE DECAL 38816-075 --- 1
G‐R DECAL GR-03 --- 1
INSTRUCTION LABEL 2613DK --- 1
ROTATION DECAL 2613M --- 1
OPTIONAL:
HI TEMP SHUT DOWN KITS:
-120
_F 48313-257 --- 1
-130 _F 48313-256 --- 1
-145 _F 48313-186 --- 1
HIGH TEMP SHUTDOWN THERMOSTAT KIT:
-145
_F 48313-172 --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
. INCLUDED WITH 46471-513 --- 1
REPAIR PUMP CASING ASSY
