ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY
10 SERIES OM−05968
MAINTENANCE & REPAIR PAGE E − 7
PARTS LIST
Pump End Assembly 14D52−(12LD477 S/G)
1 PUMP CASING 38224−505 10010 1
2 IMPELLER 38615−096 11010 1
3 SEAL ASSY 25285−856 −−− 1
4 FLAP VALVE ASSY 46413−029 −−− 1
−FLAP VALVE GASKET 38671−626 19070 1
−SMALL VALVE WEIGHT 19 10010 1
−LARGE VALVE WEIGHT 4718 10010 1
−HEX HD CAPSCREW B0403−1/2 17000 1
−LOCK WASHER J04 17000 1
5 STUD C0808 15991 6
6 FILL PLUG ASSY 48271−065 −−− 1
7 DISCH FLANGE GASKET 38687−009 20000 1
8 DISCHARGE FLANGE 38644−506 10010 1
9 HEX HD CAPSCREW B1005 15991 4
10 STREET ELBOW RS64 −−− 1
11 INTERMEDIATE 38264−333 10000 1
12 DRIVE ASSEMBLY 44162−178 −−− 1
13 HEX NUT D06 15991 8
14 SHAFT SLEEVE O-RING 25154−022 −−− 1
15 SEAL SLEEVE 11876A 16000 1
16 SPRING RETAINER 31161−042 17000 1
17 IMP ADJ SHIM SET 37J 17090 1
18 CASING GASKET SET 48211−022 −−− 1
19 STUD C0606 15991 8
20 DRIVE SCREW BM#04−03 17000 4
21 NAME PLATE 38818−021 13990 1
22 PIPE PLUG P08 15079 1
23 WEAR PLATE ASSY 46451−302 24150 1
24 LOCK WASHER J04 15991 2
25 HEX NUT D04 15991 2
26 BACK COVER GASKET 38682−015 20000 1
27 FLAT WASHER K08 15991 2
28 WING NUT BB08 15991 2
29 BACK CVR PLATE ASSY 42111−997 −−− 1
−WARNING PLATE 2613EV 13990 1
−DRIVE SCREW BM#04−03 17000 4
30 SUCTION FLANGE 38645−506 10010 1
31 HEX NUT D08 15991 4
NOT SHOWN:
STRAINER 2690 24000 1
PRIMING STICKER 6588AH −−− 1
SUCTION STICKER 6588AG −−− 1
G-R DECAL GR−03 −−− 1
DISCHARGE STICKER 6588BJ −−−−− 1
INSTRUCTION TAG 38817−085 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
