OM−00900 80 SERIES
MAINTENANCE & REPAIR PAGE E − 11
seated. This should be done quickly, in one con-
tinuous motion, to prevent the bearings from cool-
ing and sticking on the shaft.
After the bearing cones have been installed and al-
lowed to cool, check to ensure that they have not
moved away from the shaft shoulders in shrinking.
If movement has occurred, use a suitably sized
sleeve and a press to reposition the bearings
against the shaft shoulders.
If heating the bearings is not practical, use a suit-
ably sized sleeve and an arbor (or hydraulic) press
to install the bearings on the shaft.
When installing the bearing cones onto the
shaft, never press or hit against the outer
race, rollers, or roller cage. Press only on
the inner race.
Pack the bearing cups and cones with No. 2 lithium
base grease.
Press the bearing cup (31) onto the bearing cone
(32) until the cone fully engages the bearing cup.
Slide the bearing closure (33) on the impeller shaft
(27).
When installing the bearing cups on the im-
peller shaft, push against the outer race.
Never hit the rollers or roller cage.
Slide the shaft and assembled bearings into the in-
termediate bore from the drive end until the bear-
ing closure is seated squarely against the interme-
diate shoulder. Press the outboard bearing cup
(28) over the outboard bearing cone (29).
Install the same thickness of bearing adjusting
shims (22) as previously removed and secure
them with the bearing cap (23) and hardware (24
and 25). Check the shaft endplay.
NOTE
Shaft endplay should be between .003 and .005
inch (0,08 mm to 0,13 mm). Add or remove bearing
shims to establish the correct endplay.
Lubricate the bearings as indicated in LUBRICA-
TION at the end of this section.
Securing Intermediate And Drive Assembly To
Engine
(Figure 3)
Install the shaft key (26, Figure 2) in the shaft key-
way. Position the flexible portion of the coupling as-
sembly (3) on the shaft as shown in Figure 3.
NOTE
The flexible portion of the coupling must be proper-
ly positioned on the shaft. The heads of the caps-
crews in the center of the coupling must be posi-
tioned toward the pump end of the shaft.
Align the keyway in the bushing (2) with the shaft
key, and slide it onto the shaft until it is just flush
with the end of the shaft. Rotate the flexible portion
of the coupling until the tapped holes for the two
setscrews align with those in the bushing, and in-
stall the setscrews.
Make certain that the flexible portion of the
coupling is mounted as shown in Figure 3.
This is critical.
If the coupling is not prop-
erly positioned on the shaft, the coupling
parts may not fully engage, or a pre-load
condition can cause premature bearing
failure.
The end of the shaft must be just flush with
the face of the bushing. This will allow the
two portions of the coupling to fully engage
when the intermediate is secured to the en-
gine bellhousing, without pre-loading the
bearings.
With the flexible portion of the coupling and the
bushing properly positioned on the shaft, tighten
the two setscrews in an alternating sequence until
