SUPER T SERIES OM-06183
MAINTENANCE & REPAIR PAGE E - 7
PARTS LIST
T6A60S-(SAE 4/10) Pump End Assembly
1 . PUMP CASING SEE NOTE BELOW 1
2 REPAIR ROTATING ASSY 44163-349 --- 1
3 CLAMP BAR SCREW 31912-009 15000 1
4 . MACHINE BOLT A1014 15991 2
5 CLAMP BAR 38111-004 11010 1
6 FILL COVER ASSY 42111-344 --- 1
-DRIVE SCREW BM#04-03 17000 2
-WARNING PLATE 38816-097 13990 1
-COVER GASKET 50G 19210 1
7 . PIPE PLUG P04 15079 2
7A PIPE PLUG P04 15079 1
8 . PIPE PLUG P08 15079 1
9 HEX HD CAPSCREW B0806 15991 4
10 LOCKWASHER J08 15991 10
11 ROT ASSY ADJ SHIMS 13131-3 17040 8
12 BEARING HSG O‐RING S1676 --- 1
12A BACK COVER O‐RING S1676 --- 1
13 WEAR PLATE ASSY 46451-723 24150 1
14 . CASING DRAIN PLUG P20 10009 1
15 BACK COVER O‐RING 25152-453 --- 1
16 BACK CVR PLATE ASSY 42111-803 --- 1
-DRIVE SCREW BM#04-03 17000 4
-WARNING PLATE 2613EV 13990 1
-PRESS RELIEF VALVE 26662-005 --- 1
-WARNING DECAL 38816-302 --- 1
17 LOCK COLLAR 38115-551 15001 4
18 HEX HD CAPSCREW B0804-1/2 15991 4
19 ADJUSTING SCREW 31871-070 1500X 4
20 . STUD C1213 15991 4
21 BACK COVER NUT 31871-073 15000 4
22 CVR PLATE HANDLE 12354 13010 1
23 HEX HD CAPSCREW B0604 15991 2
24 LOCKWASHER J06 15991 6
25 HEX NUT D06 15991 4
26 HEX HD CAPSCREW B1211 15991 8
27 LOCKWASHER J12 15991 16
28 SUCTION FLANGE 11402 10010 1
29 CHECK VALVE PIN 11645 17010 1
30 SUCTION FLANGE GSKT 11402G 19370 1
31 SUCT CHK VALVE ASSY 46411-064 --- 1
32 DISCH FLANGE GSKT 25113-036 --- 1
33 DISCHARGE FLANGE 1758 10010 1
34 HEX HD CAPSCREW B1208 15991 8
35 PIPE NIPPLE T96 15070 1
36 PIPE ELBOW R96 11990 1
NOT SHOWN:
DRIVE SCREW BM#04-03 17000 4
LUBE DECAL 38817-084 --- 1
WARNING DECAL 2613FE --- 1
NAME PLATE 38818-040 13990 1
SUCTION STICKER 6588AG --- 1
PRIMING STICKER 6588AH --- 1
DISCHARGE STICKER 6588BJ --- 1
SUPER “T” DECAL 38812-089 --- 1
STRAINER 7823A 24000 1
INSTRUCTION TAG 38817-023 --- 1
G‐R DECAL GR-03 --- 1
DRIVE ASSEMBLY 44162-119 --- 1
OPTIONAL:
ALLOY STEEL WEAR
PLATE ASSY
46451-729 24160 1
DISASSEMBLY TOOL 12859 24000 1
SEWAGE SLUDGE
PRESS RELIEF VALVE
46431-628 --- 1
CLEANOUT KIT 48783-010
AIR RELEASE VALVES:
-10# COMP SPRING GRP33-07A --- 1
-25# COMP SPRING GRP33-07 --- 1
-80# COMP SPRING GRP33-07B --- 1
AIR MATE
t
AUTOMATIC AIR RELEASE VALVES:
-BUNA‐N GRP33-30 --- 1
-FLUOROCARBON GRP33-30A --- 1
-EPDM GRP33-30B --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
. INCLUDED W/REPAIR PUMP CASING ASSY 46472-722 --- 1
