SUPER T SERIES
OM-06190
MAINTENANCE & REPAIR
PAGE E - 8
PARTS LIST
44163-485 Repair Rotating Assembly
ITEM
NO.
PART NAME
PART
NUMBER
MAT'L
CODE
QTY
1
IMPELLER
38615-087
1718H
1
2
CARTRIDGE SEAL ASSY
46513-159
---
1
3
SEAL PLATE GASKET
10959G
19410
1
4
BALL BEARING
S616
---
1
5
BEARING HOUSING
38251-526
17180
1
6
VENTED PLUG
4823A
17040
1
7
AIR VENT
26717-006
---
1
8
REDUCING PIPE BUSHING
AP0802
17040
1
9
BALL BEARING
S1030
---
1
10
DRIVE FLANGE
38545-006
10000
1
11
SHAFT KEY
N0608
17040
1
12
IMPELLER SHAFT
38514-823
1706H
1
13
OIL SEAL
S1917
---
1
14
SNAP RING
24124-425
---
1
15
HEX HD CAPSCREW
21632-938
---
8
16
LOCK WASHER
J06
17090
8
17
DRIVE FLANGE GASKET
38683-478
19410
1
18
OIL SEAL
S1917
---
1
19
OIL SEAL
S1917
---
1
20
HEX HD CAPSCREW
B0805-1/2
17090
4
21
LOCK WASHER
J08
17090
4
22
SEAL PLATE
38272-254
1718H
1
23
SEAL CAVITY DRAIN PLUG
P04
17090
1
24
BEARING CAVITY DRAIN PLUG
P04
17090
1
25
BEARING CAVITY SIGHT GAUGE
26714-021
---
1
26
SEAL CAVITY SIGHT GAUGE
26714-021
---
1
27
PIPE PLUG
P12
17090
1
28
GUARD ASSY
42381-509
24152
2
29
IMPELLER ADJ SHIM SET
5091
17090
REF
30
SHAFT SLEEVE O‐RING
25154-026
---
REF
31
SHIPPING PLUG
11495B
15079
2
32
ROTATING ASSY ADJ SHIM
13131-3
17040
8
33
BEARING HOUSING O‐RING
25154-454
---
1
34
DRIVE SCREW
BM#04-03
17090
2
35
S/N PLATE
2613GG
17020
1
NOT SHOWN:
ROTATION DECAL
2613M
---
1
INSTRUCTION TAG
6588U
---
1
INDICATES PARTS RECOMMENDED FOR STOCK
