ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT’L
CODE QTY
ULTRA V SERIES OM−06267
MAINTENANCE & REPAIR PAGE E − 9
PARTS LIST
V3A60−(SAE 4/10) Pump End Assembly
1 PUMP CASING 38224−614 10000 1
2 REPAIR ROTATING ASSY 44163−492 −−− 1
3 DRIVE SCREW BM#04−03 17000 4
4 NAME PLATE 38818−149 13000 1
5 STUD C1213 15991 4
6 PIPE PLUG P20 10009 1
7 WEAR PLATE ASSY 46451−758 24150 1
8 O-RING 25152−273 −−− 1
8A O-RING 25152−273 −−− 1
9 LOCK WASHER J06 15991 4
10 HEX NUT D06 15991 2
11 O-RING S1674 −−− 1
11A O-RING S1674 −−− 1
12 BACK COVERPLATE ASSY 42111−831 −−− 1
−PRESS RLV VALVE 26662−007 −−− 1
−WARNING PLATE 2613EV 13990 1
−DRIVE SCREW BM#04−03 17000 4
−WARNING DECAL 38816−302 −−− 1
13 LOCK WASHER J08 15991 8
14 HEX HD CAPSCREW B0804 15991 4
15 BACK COVER NUT 31871−073 15000 4
16 HEX HD CAPSCREW B0604−1/2 15991 2
17 HANDLE 12354 13010 1
18 ADJUSTING SCREW 31871−070 15000G 4
19 LOCK WASHER 38115−551 15001 4
20 HEX HD CAPSCREW B1009 15991 8
21 LOCK WASHER J10 15991 12
22 PIPE PLUG P04 15079 2
23 SUCTION FLANGE 38641−534 10000 1
24 SUCTION FLANGE GSKT 38683−502 19370 1
25 ROLL PIN 21154−229 −−− 2
26 FLAP VALVE ASSY 46411−147 24010 1
27 FLAP VALVE COVER 38346−621 17040 1
28 LOCK WASHER J05 15991 4
29 HEX HD CAPSCREW B0504 15991 4
30 SQ HD BOLT A1014 15991 2
31 FILL COVER ASSY 42111−437 −−− 1
−FILL PORT GASKET 50G 19210 1
−WARNING PLATE 38816−097 13990 1
−DRIVE SCREW BM#04−03 17000 2
32 CLAMP BAR 38111−004 11010 1
33 HEX HD CAPSCREW B1010S 15991 1
34 3" FLANGED ELBOW 25532−105 −−− 1
35 HEX HD CAPSCREW B1007 15991 4
36 PIPE PLUG P16 10009 1
37 DISCH FLANGE GSKT 25113−033 −−− 1
38 HEX HD CAPSCREW B0805−1/2 15991 4
39 COUPLING KIT 48112−005 −−− 1
40 SPACER 33221−022 17040 4
41 PIPE PLUG P08 15079 2
NOT SHOWN:
G-R DECAL GR−03 −−− 1
INSTRUCTION TAG 38817−085 −−− 1
ULTRA V" DECAL 38816−342 −−− 1
SUCTION STICKER 6588AG −−− 1
LUBE DECAL 38817−084 −−− 1
DISCHARGE STICKER 6588BJ −−− 1
PRIMING STICKER 6588AH −−− 1
WARNING DECAL 2613FE −−− 1
4" STRAINER 2690C 24000 1
OPTIONAL:
DISASSEMBLY TOOL 48711−020 −−− 1
FLAP VALVES:
[ −FLUOROCARBON 46411−148 24010 1
−BUNA-N 46411−149 24010 1
−EPDM 46411−150 24010 1
FLANGE KITS:
3" NPT DISCH KIT
48213−119 −−− 1
4" X 3" ASA SUCTION/DISCHARGE
SPOOL KIT
48213−143 −−− 1
−4" ASA SUCTION
SPOOL KIT 48213−142 −−− 1
−3" ASA DISCHARGE
SPOOL KIT 48213−120 −−− 1
4" X 3" METRIC SUCTION/DISCHARGE
SPOOL KIT
48213−121 −−− 1
−4" METRIC SUCTION
SPOOL KIT 48213−144 −−− 1
−3" METRIC DISCHARGE
SPOOL KIT 48213−145 −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
