OM−06341 PA SERIES
MAINTENANCE & REPAIR PAGE E − 15
PARTS LIST
44163−430 Repair Rotating Assembly
1 IMPELLER 38615−092 11010 1
2 SEAL ASSY 46512−149 −−− 1
3 SEAL PLATE 38272−256 10000 1
4 OIL SEAL 25227−771 −−− 1
5 SIGHT GAUGE S1471 −−− 2
6 BEARING HOUSING 38251−513 10000 1
7 PIPE PLUG P08 15079 3
7A BRG HSG DRAIN PLUG P08 15079 1
7B SEAL CVTY DRAIN PLUG P08 15079 1
8 VENTED PLUG 4823A 15079 1
9 REDUCER PIPE BUSHING AP0802 15079 1
10 AIR VENT S1530 −−− 1
11 HEX HD CAPSCREW B0805−1/2 15991 4
12 LOCKWASHER J08 15991 4
13 HEX HD CAPSCREW 21632−938 15991 6
14 LOCKWASHER J06 15991 6
15 OIL SEAL S1907 −−− 1
16 DRIVE FLANGE 38545−020 10000 1
17 INTERM GUARD ASSY 42381−509 24152 2
18 BRG HOUSING GSKT 38683−474 18000 1
19 RETAINING RING S720 −−− 1
20 THRUST WASHER 31134−115 15000 1
21 OUTER BALL BEARING 23422−414 −−− 1
22 SHAFT KEY 24113−603 −−− REF
23 IMPELLER SHAFT 38515−592 1706H 1
24 SHAFT SLEEVE 31163−019 1706H 1
25 INNER BALL BEARING 23422−019 −−− 1
26 SOC HD CAPSCREW DM1004S 17090 1
27 IMPELLER WASHER 31514−015 17000 1
28 SHAFT SLEEVE O-RING 25154−131 −−− REF
29 IMPELLER ADJ SHIM SET 48261−057 −−− REF
30 SEAL PLATE O-RING 25152−381 −−− 1
31 BRG HSG O-RING S1676 −−− 1
32 ROT ASSY ADJ SHIM 13131−3 17040 12
33 SHIPPING PLUG 11495B 15079 1
34 LOCK WASHER J05 15991 4
35 HEX HD CAPSCREW B0504 15991 4
NOT SHOWN:
INSTRUCTION TAG 6588U −−− 1
INDICATES PARTS RECOMMENDED FOR STOCK
