NXG Speakers Three-Year Limited Warranty
If the NXG speaker system proves to be defective in workmanship or
materials within three years from the date of the original customer’s
purchase, we will, at our option, repair or replace the defective product.
Limitation of Implied Warranties
Any implied warranties, including warranties of merchantability and
fitness for a particular purpose, are limited in duration to the length
of this warranty.
Exclusion of Certain Damages
NXG’s liability for any defective product is limited to repair or
replacement of the product at our option. NXG shall not be liable
for incidental or consequential damages of any kind or character
because of product defects. Some states do not allow limitations on
how long an implied warranty lasts and/or do not allow the exclusion
or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply.
This Warranty Does Not Cover:
• Damage caused by abuse, accident, misuse, negligence, or
improper operation.
• Any product whose serial number has been altered, defaced,
or removed.
• Products that have been altered or modified.
• Normal wear and maintenance.
• Damages caused by shipping. (All claims for shipping damage
must be made with the carrier.)
Warranty Service
Warranty service must be performed by an authorized service center,
usually a NXG speaker systems dealer or its authorized agent. You
may obtain a list of authorized service centers by contacting NXG. All
warranty repairs must be accompanied by the original bill of sales. No
other document is acceptable or is required. This warranty gives you
specific legal rights, and you may also have other rights which vary
from state to state.
NXG reserves the right to revise speaker system specifications without notice.
Operational Check
After making all connections it’s a good idea to make sure everything
is working properly. Turn on your surround or stereo system making
sure the volume control is turned down and that the balance control
is in the center position. Activate a musical or movie source. Gently
turn up the volume, you should hear sound coming from your new
NXG speaker. If no sound is heard from the speaker, switch off the
system immediately and check for open or loose connections, wrong
polarity or shorts, or proper source selection.
FIG. 5A
NX-PRO6222DVC Specifications
Maximum Power Handling: 5 - 120 watts
Sensitivity: 90dB @ 1 watt/1 meter
Frequency Response: 40 Hz-22,000 Hz
Driver Complement: 6 1 /
2
˝ (165mm) dual voice coil metallic
anodized injection-molded radiative cone woofer
with rubber surround
Dual 3 /
4
˝ (19mm) liquid-cooled metallic anodized dome tweeters
Nominal Impedance: 8 ohms in two channel (stereo) mode,
4 ohms mono mode
Grille: Corrosion-resistant powder coated aluminum
Overall Dimensions: 9 1 /
4
˝ (diameter) round x 3 3 /
4
˝ D
Required Ceiling Cut-out: 8 1/
8
˝ (diameter) round
16648 North 94th Street
Scottsdale, AZ 85260
1-800-733-0008
For single
channel
operation,
set switch to
4 ohm mode
For two
channel
operation,
set switch to
8 ohm mode
4 ohm /8 ohm
switch
4 ohm /8 ohm
switch
FIG. 5B
