4
1. HP6E Main Features
• 10 TRS inputs, 5 stereo channels
• Mix add control for each amplifier output
• 6 class A stereo headphone amplifiers
• Nominal output @ 32Ohm 600mw per channel
• Frequency response @100mw output 20Hz-20kHz +- 0.3 dB
• Built in flash memory for last state memory save
• Sturdy metal construction
• 1U 19” rack-mountable device
2. INTRODUCTION
The HP6E is a high-quality, powerful, flexible, and reliable six (6) channel headphone
amplifier housed in a sturdy 1RU 19” standard rack-mountable metal chassis. The
HP6E boasts a variety of improvements over the standard headphone amplifiers in-
cluding improved frequency response, additional power, digital control of input selec-
tion and a fifth mix input. Built in flash memory has also been added to allow for last
state memory recall of the input selection for each channel... perfect for saving critical
studio time. The HP6E’s flexible design allows any of the four (4) available audio input
source signals can be routed to any of the 6 Class A headphone amps provided on
the HP6E. An additional fifth stereo signal can also be mixed into each individual
headphone channel. This allows for endless application support including studio mo-
nitoring, live monitoring, in ear individual mixing, signal distribution and more.
3. THE DESIGN CONCEPT
3.1 High quality components and design
The philosophy behind SM Pro Audio products guarantees a no-compromise circuit
design and employs the best choice of components.
3.2 Inputs and outputs
All inputs and outputs are secured firmly to the exterior chassis housing. This ensu-
res robust quality and confidence in performance under all conditions.
4. HP6E FRONT panel
The panel has 6 mix controls, 6 level controls, 6 selector switches, 6 1/4” 6.5mm
output jacks and a power switch.
4.1 LED indicators
The LED indicators are an easy way for the user to see which one of the
inputs they are listening to on the HP6E.
4.2 Selector switch
Use this switch to select which input you want to listen to. The inputs will
keep scroling each time you press the button. The state of the input (the
chosen number) will automatically be saved when the unit is switched OFF.
4.3 Mix volume
The 5th stereo input on the HP6E is the MIX input. You are able to dial in as
much as needed of this input and mix it together with the other selected input.
