STEP 1
Attach ULTI Boom to mic stand.
STEP 3
Lessen the ergonomic knobs to adjust boom length, then tighten ergonomic knobs.
STEP 2
Loosen the oversized rotation hub to adjust boom angle up or down, then tighten oversize
rotation hub.
3
set-up set-up
ULTI-BOOM-TB
(Telescoping)
ULTI-BOOM-FB
(Fixed)
ULTI-BOOM-TB
(Telescoping)
ULTI-BOOM-FB
(Fixed)
&
Loosen
Loosen Loosen
Tighten
Ergonomic knobs
Ergonomic knobs
Universal Mic
Attachment
Heavy-duty
Counter-weight Oversized
Rotation Hub
Ergonomic knobs
Universal Mic
Attachment
Heavy-duty
Counter-weight
Oversized
Rotation Hub
ULTI-BOOM-TB (Telescoping)
ITEM #17203
ULTI-BOOM-FB (Fixed)
ITEM #17202
Loosen
Loosen
2
3
2
STEP 4 Universal Mic Attachment
To adjust US to metric, use tool provided
or 1.5 Allen Wrench to unlock threads.
Turn US threads counter clockwise until it
is removed. US MIC-Lock will come off too.
STEP 5 Universal Mic Attachment
After choosing desired thread, place
microphone on universal mic attachment.
Then turn MIC-Lock counter clockwise to
lock mic in place.
Metric
US
5
5
MIC-Lock
LOCKED
LOCKED
MIC-Lock
Metric
US Mic Lock
Mic
Tool or 1.5
Allen
Wrench
US
4
WORKING PARTS
Tighten
1
