Set-up – Ultimate Support AX-48 Pro Mic Boom User Manual
Page 2
STEP 1: Locate groves on top plate.
STEP 3: Remove accessory cap.
STEP 5: Using provided allen wrench, screw
bolts into place. Do not over tighten.
STEP 6: Attach Ulti-Boom to the top of the
accessory cap and adjust as desired.
STEP 4: Replace accessory cap with adapter cap.
STEP 2: Using a flat tip screw driver, remove
accessory cap by wedging head into
groves and gently applying pressure.
SET-UP
1.
2.
3.
4.
5.
6.
Grove
Grove
PARTS INCLUDED:
A. Mic Boom
B. Adapter
C. (2) Bolts
D. Allen Wrench
A.
B.
C.
D.
