Allied Solutions Auto Pit User Manual
Auto pit, Self forming pit kit

Self Forming Pit Kit
Auto Pit Benefits
• Self squaring
• 3”X3”X1/4” Curb angles provide the strength and
reliability of standard formed pit angles at the top
edge of the pan
• Simple bolt together design removes the need for
standard pit forming
• Saves time and money
• Electrical cut outs for powered docks included
• Unit is quickly secured to the base slab
• All concrete studs are in place for strong interlac-
ing with the base slab
• Unit is pre-finished in machinery grey
• Pit kit is standard dock pit size so levelers can be
easily removed and replaced
• Comes in all standard sizes 6’X6’, 6.5’X6’, 7’x6’,
6’X8’6.5’X 8’, 7’X8’ and specialty sizes
• Made in the USA
Auto Pit
