NOTICE:
The use of thread sealants and lubricants on threads also provides lubricity. Over-
application of torque can damage to the valve port or component.
7. Properly assembled valve components will immediately seal to moderate pressure
(100 PSI or less). For maximum pressure resistance, allow the Loctite 567
1
or
RectorSeal No. 5
2
thread sealant to cure for 24 hours. PTFE tape typically does not
require curing to achieve maximum pressure resistance.
1
Loctite and Loctite 567 are registered trademarks of Henkel Ag & Co.
2
RectorSeal No.5 is a registered trademark of RectorSeal Corporation.
Maintenance
Ultra Setter
™
Pressure Independent Control Valves Installation, Operation and Service Manual
13
