SERVICE INSTRUCTIONS FOR PUMPS WITH FLUSH PACKING (VSC-PF, VSCS-PF)
(See special instructions for pumps 10 x 12 x 17, 12 x 14 x 12 1 /
2
and 8 x 10 x 17)
TO REPLACE THE PACKING OR SHAFT SLEEVE:
4. Remove bearing cover and release cam lock.
5. Remove bearing housing capscrews. Pull housing and bear-
ing from pump shaft using capscrews in jackscrew holes.
6. Remove flush tube and capscrews from the stuffing box.
7. Remove packing gland and packing rings from stuffing box.
8. Loosen outer two set screws in shaft sleeve drive collar
and pull entire shaft sleeve with stuffing box from the
pump shaft.
9. To assemble, clean out stuffing box thoroughly and
assemble to volute coverplate.
10. Apply anti-seize compound only to the area of the shaft
that will be under the sleeve. Install shaft sleeve on shaft.
Position sleeve drive collar outer holes over undercut in
shaft and tighten set screws. If sleeve is pitted or scored,
the sleeve should be replaced.
11. Insert two packing rings into the stuffing box, staggering
the joints 90°.
12. Install the lantern ring and then the other two packing
rings, staggering them 90°.
13. Install, but do not tighten packing gland.
IMPORTANT! When working on the packing on the non-
coupler end, it is necessary to force the pump shaft back
from the coupler end as far as possible and to hold it in
this position while installing and locking the bearing to the
shaft. Also, when replacing both packings, the packing on
the non-coupler end of the pump should be installed first.
WARNING: Excessive Pressure Hazard
Make certain internal pressure is relieved before con-
tinuing. Failure to follow these instructions could result in
serious personal injury or death, or property damage.
SPECIAL INSTRUCTIONS FOR PUMPS (VSCS-S & VSCS-D) 8 x 10 x 17
TO REPLACE THE SEAL OR SHAFT SLEEVE:
4. Remove bearing cover and release bearing cam lock.
5. Remove bearing housing capscrews. Pull housing and bear-
ing from pump shaft using capscrews in jackscrew holes.
6. Remove seal plate capscrews and flush tube.
7. Remove outer two screws in shaft sleeve drive collar and
loosen two inner set screws one turn.
8. Pull entire sleeve and seal assembly from shaft.
9. To assemble the pump, clean shaft sleeve and pump shaft.
Replacer shaft sleeve if pitted or scored. If replacing the
seal, remove shaft O-ring and replace (included in seal kit).
NOTE: If installing -D seals refer to steps 10-12 on -D
instructions, then skip to step 15.
10. Lubricate O-ring on stationary seal seat (carbon) with sili-
cone grease or soapy water. DO NOT USE PETROLEUM
LUBRICANT! Position in seal housing.
11. Place shaft sleeve in drive collar and tighten the two dog
point set screws in holes provided.
12. Set shaft sleeve and drive collar assembly on end and
place assembly aid spacer around shaft sleeve. Position
against drive collar.
13. Place seal housing with carbon over the end of the sleeve
against assembly aid spacer.
14. Lubricate O-ring in rotating seal assembly with silicone
grease or soapy water. DO NOT USE PETROLEUM
LUBRICANT! Slip rotating seal assembly on the end of the
sleeve and place against carbon.
15. Compress rotating seal assembly to a 1 /
4
" space between
the seal parts that house the compression springs. Tighten
set screws.
16. Apply anti-seize compound only to the area of the shaft
that will be under the sleeve. Place seal housing gasket in
position and slide complete assembly over pump shaft.
IMPORTANT! When working on the seal on the non-
coupler end, it is necessary to force the pump shaft back
from the coupler end as far as possible and to hold it in
this position while installing and locking the bearing to the
shaft. Also, when replacing both seals, the seal on the
non-coupler end of the pump should be installed first.
17. Install the bearing housings. Clean and regrease the bear-
ings and insert into bearing housings. Push the pump shaft
back from the motor end as far as possible, using a lever if
necessary. Hold the shaft in this position. On the outboard
bearing tap inner race until it is properly positioned against
the shaft shoulder. Install and lock the cam lock into posi-
tion. If the shaft and bearing are properly positioned, the
cam lock set screw will fall in the center of the shaft under-
cut. Release the shaft. Install the outboard bearing cap.
Install the inboard bearing by tapping the inner race until it
contacts the shaft shoulder, lock the bearing in place with
the cam lock. Install the inboard bearing cap.
18. Push on the drive collar until the seal housing is against
the coverplate, bolt into place.
19. Tighten down collar set screws in undercut of shaft.
Remove assembly aid spacer and connect flush tubing to
seal housing.
20. Replace drain plug.
21. Install coupler and align, following the instructions located in
the section titled “Coupler Alignment.”
22. Install coupler guard. Refer to separate instructions titled
“Hex Coupler Guard Removal/Installation.”
23. Open isolation valves and check pump for leaks. If not
leaking, return pump to service.
WARNING: Excessive Pressure Hazard
Make certain internal pressure is relieved before con-
tinuing. Failure to follow these instructions could result in
serious personal injury or death, or property damage.
