Assembly &

Installation Instructions

H-223

Assembly & Installation Instructions 1-1

1.0 Introduction

The

W

ATER

LOG

®

H-223 is a rugged, high-gain Yagi antenna designed for use with fixed location GOES

Satellite Data Collection Platforms. The antenna has two 5-element Yagi antennae mounted on an

extruded aluminum boom. The one-piece reflector and director elements lock firmly into place with a

unique ½-turn cam-lock mechanism.

Key features include:

Rugged, heavy duty construction

High gain

Circular polarization

Fully adjustable mount fits on a 2-inch pipe mast

Can be disassembled for easy transport and shipping

2.0 Assembly

The

W

ATER

LOG

®

H-223 antenna is shipped disassembled in a 4" x 4" x 48" box. You will need a 6-inch

adjustable wrench and a pair of pliers to assemble the antenna. Unpack and familiarize yourself with the

parts. You should have:

Quan

Description

1

Adjustable mount, complete with 2 setscrews, 2- bolts, 2-nuts and 4-washers

1

1" square x 38" boom

4

Dipole elements (7" long, with threaded stud)

1

Reflector-A element (14-3/4" long, with eccentric cam)

1

Reflector-B element (14-3/4" long, with round notch)

3

Director-A elements (13-1/4" long, with eccentric cam)

3

Director-B elements (13-1/4" long, with round notch)

Refer to the assembly drawing for the proper location of each element. Install the elements as follows:

Install three sets of director elements (13-1/4" long)

Install one set of reflector elements (14-3/4" long)

Install four dipole elements (7" long with threaded stud)
