Description of run screen box functions from left to right:
Option Description
Barometer reading Highlight and press enter to calibrate the barometer
Salinity compensation
value Highlight and press enter to adjust salinity
compensation value
SAVE
Highlight and press enter to save current data to
memory
DATA
Highlight and press enter to view and/or erase saved
data
NAVIGATING IN THE SYSTEM SETUP MENU
When in the System Setup menu, the up and down arrow keys will move the
highlighted bar up and down the system setup options. See the System Setup
menu section of this manual for more information about these options.
FIRST POWER ON
The instrument will step through an initial configuration when powered on for the
first time. This will set the language, sensor, and membrane options. Use the up
or down arrow keys to highlight the appropriate language, sensor, and membrane,
then press enter to confirm (Figures 6, 7, and 8). The Sensor Type must be
configured for the sensor installed. Failure to do this may result in damage not
covered under warranty. If an incorrect option is selected, it may be changed in
the System Setup menu.
Select Sensor Type:
7
Polaro (black)
Galvanic (grey)
Use ST to select
sensor type
Press to confirm
Select Language:
7
English
Français
Español
Deutsch
Use ST to select
Language
Press to confirm
Figure 6, Language selection
Select Membrane
Type:
71.25 (Yellow)
2.0 (Blue)
Use ST to select
membrane
Press to confirm
Figure 8, Membrane selection Figure 7, Sensor selection
