Logging Data
1.) To begin the process of logging data,
synchronize the PC clock with the Level
Scout clock by selecting Other. Check
Synchronize/Xducer(s) with PC and select
Send
.
2.) Select Edit Test. Wait for the transducer
to upload information to the PC. Select
the two Rel radio buttons. Select Send.
This programs a 5 minute test, sampling
pressure and temperature once per
minute. Wait 5 minutes for the test to
conclude.
Extracting Logged Data
1.) To extract logged data, select Extract Test
Data. Check Extract Scans Above and
select Send.
2.) Select File/View AutoLog Files from the
top menu.
3.) Select the file and select Open to view the
AutoLog test. Select the arrow for the drop
down menu in the Display cell and select
Both. Complete pressure
and temperature data are
displayed on the non-
scrolling trend graph.
4.) Use the Time/Scan/
Measurement/
Other tabs to
customize future
AutoLog tests.
CONTACT
INFORMATION
YSI Incorporated
1725 Brannum Lane
Yellow Springs, OH
45387
+1 937-767-7241
800-897-4151 (USA)
Fax: +1 937 767-1058
[email protected]
www.ysi.com
Item # 776-0-0
A605824
Rev B
June 2009
