Xylem IM223 R04 Hydrovar Pump Control User Manual
Page 16
16
HVM3407, HVM3410, HVM3415
All dimensions in inches!
Drawings are not to scale!
Dimensions are nominal
type
Weight [lbs]
Basic
Master / single
7.5, 10, 15 HP
16.9 17.8
3 Ph
a … minimum centre-distance between HYDROVARs
17"
b … minimum header space for maintenance
12"
9.4
10.2
10.9
3.35
3.35
6.7
9.9
10.2
diMensions and WeiGHts
