7
3/07
SymCom warrants its standard products against defects in material or workmanship for a period of
five (5) years from the date of manufacture except for Power Perfect which is warranted for twelve
(12) months. All third-party products are warranted by their manufacturer and are handled as a pass-
through warranty by SymCom. All custom and private labeled products are warranted for eighteen
(18) months unless otherwise stated in writing. The liability of SymCom is limited, at its option, to
replace, repair, or credit at the purchase price, for any devices which are returned during the warranty
period that prove to be defective.
233-P SPECIFICATIONS
Single-Phase Line Voltage 230VAC
Load Range 1/3 – 3hp
Frequency 50/60Hz
Note: 50Hz will increase all delay timers by 20%
Operating Points
Overload 125% of calibration point
Underload (dry-well) Adjustable
Overvoltage 265VAC
Undervoltage 190VAC
Number of restarts allowed in a 60-second
period (rapid-cycling)
4
Trip Delay Times
Overload 5 seconds
Dry-well 4 seconds
Restart Delay Times
Over/undervoltage 2 seconds
All other faults manual, 2-225 minutes
Output Contact Rating—SPDT
3hp, 240VAC
(17 amps max.)
Electrostatic Discharge (ESD) IEC 1000-4-2, Level 2, 4kV contact , 6kV air
Power Consumption 5 Watts (max.)
Weight 14 oz.
Operating Temperature -40° to 70°C (-40° to 158°F)
Safety Marks
UL UL508
CSA LR 46510-12
