9

Pin Assignment

Signal

PIN Description PIN Description
1 Red 9 +5V
2 Green 10 GND
3 Blue 11 GND
4 GND 12 DDC_SDA
5 Detect 13 HSYNC
6 Red_GND 14 VSYNC.
7 Green_GND 15 DDC_SCL
8 Blue_GND

Technical Information

Signal

Digital Video Input Connector : DVI – D (option)

1

TX1-

TX0-

2

TX1+

18

Shield (TX2 / TX4)

NC

12

20

5

13

21

6

22

23

8

Hot plug detect

TX2-

TX2+

9

17

10

TX0+

11

Shield (TX0 / TX5)

3

Shield (TX1 / TX3)

19

4

NC

NC

NC

NC

NC

+5V power

DDC-Serial Clock

14

Shield (TXC)

7

15

Ground (+5V)

TXC+

NC

DDC-Serial Data

16

TXC-

24
