Acer V226HQL - Manual

Attaching the monitor to the base
Acer LCD Monitor Quick Start Guide (QSG)
Important safety instructions
Please read the following instructions carefully.
1. To clean the LCD monitor screen:
f
Turn off the LCD monitor and unplug the power cord.
f Spray a non-solvent cleaning solution onto a rag and clean the screen gently.
2. Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely
damage it.
3. Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.
4. Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform
servicing of any nature.
5. Store the LCD monitor in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the LCD monitor
outside this range may result in permanent damage.
6. Immediately unplug your monitor and call an authorized technician if any of the following circumstances
occur:
f
Monitor-to-PC signal cable is frayed or damaged.
f Liquid spills onto the LCD monitor or the monitor is exposed to rain.
f The LCD monitor or case is damaged.
Package contents
LCD
monitor
Power cord
Audio
cable
(optional)
VGA cable
(optional)
DVI cable DP cable Quick start
(optional) (optional) guide
Connecting your monitor to a computer
1. Turn off your computer and unplug your computer's power
cord.
2. Connect the signal cable to the VGA and/or DVI-D (optional)
and /or DP (optional) input socket of the monitor, and
the VGA and/or DVI-D (optional) and/or DP (optional)
output socket of the graphics card on the computer. Then
tighten the thumbscrews on the signal cable connector.
3. Optional: Connect the audio input socket (AUDIO IN) of the
LCD monitor and the line-out port on the computer with
the audio cable.
4. Insert the monitor power cable into the power port at the
back of the monitor.
5. Plug the power cords of your computer and your monitor
into a nearby electrical outlet.
English
Attaching the monitor to the base
1 Remove the monitor base from the packaging and place it on a stable and level workspace.
2 Remove the monitor from the packaging.
3 Align the release button at the buttom of the monitor with the corresponding slot at the bottom of
the base. A clicking sound signifies that the monitor has been securely attached to the base.
Attaching the monitor to the base
LR60441
& 86
Attaching the monitor to the base
