7
INSTALLATION
To install the monitor to your host system, please follow the steps as given
below:
Steps
1. 1-1
1-2/1-3
Connect Video Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the VGA video cable to the computer.
2. Connect the USB Cable(Optional)
3.Connect the Audio Cable(Only Audio-Input Model)(Optional)
4. Connect pow er adapter and power cord
Connect the pow er adapter and power cord to the monitor, then to
a properly grounded AC outlet.
5. Power-ON Monitor and Computer
Power-ON the monitor first, then power-ON the computer.
This sequence is very important.
6. If the monitor still does not function properly, please refer to the
troubleshooting section to diagnose the problem.
Connect HDMI or MHL Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer or connect MHL
cable to the portable device.
4
HDMI HDMI VGA
USB
3 2 1-2 1-1 1-3
HDMI
DVI VGA
USB
1-1 1-2 1-3
3 4
2
