English – Acer X1237 User Manual
Page 46
36
English
5
Adjust the angle and positioning as necessary.
Note: The appropriate type of screw and washer for each model is
listed in the table below. 3 mm diameter screws are enclosed in
the screw pack.
Models
Screw Type B
Washer Type
Diameter (mm)
Length (mm)
Large
Small
X1130P/X1130PA/
X1130PS/X1230P/
X1230PA/X1230PK/
X1230PS/X1237
3
25
V
V
30
Allen Key
Tightening Screw
Allen Key
Tightening Screw
119 mm
189 mm
Screw M3
Depth 9.5 mm
